Leica Disto S910 Laser Distance Meter
The DISTO S910 features the best of LDM technology from Leica Geosystems. It can measure the distance between multiple points from one location. It has a Smart Base for even more measuring options and functions. It can export data to CAD. And it has WLAN, Bluetooth®, and USB connectivity. Simply put, the S910 is our Master DISTO.
Features :
- Smart Base for P2P Technology
- Pointfinder with 4x zoom for effortless targeting
- X-Range Power Technology for maximum measurement functioning
- 360° tilt sensor
- DXF data capture
- Data transfer in real-time with WLAN
- Bluetooth® Smart
- Free Leica DISTO™ sketch App
Package includes :
- Leica DISTO™ S910 laser distance meter
- Smart Base Extension
- Holster
- Hand loop
- USB charger incl. 4 plugs
Contact Us for Best Price
Description
Measure anything, anytime, anywhere.
Measure quickly and accurate distances between two points from a single location with the Leica DISTO™ S910 laser distance meter. Generate effortlessly as-built documentation, determine rooftop dimensions and integrate information into CAD or BIM software for even 3D conceptions. This improved workflows saves valued time and money. All of this at distances of up to 300 meters.
The Disto S910 features Integrated Smart Base which enables this handheld laser to measure distances between two angles and inclinations at the same time. With the innovative X-Range Power Technology and 4x magnification Pointfinder on board, the Leica Disto S910 guarantees accurate measuring performance even in poorly reflecting objects. It integrates measurement data in CAD format which can be saved into a DXF file or even as 3D data.
In addition, the Leica S910’s data can be transferred instantly to PC’s, smartphones and tablets via WLAN, Bluetooth Smart technology, or with the downloadable free Leica Disto sketch app. With an IP54 rating, this laser measuring tool is resistant from dust and water splashes. Using the included Li-ion battery pack, this laser distance meter lasts up to 4,000 measurements.
Specification
|
General
|
|
| Measuring Accuracy | ±1/16-inch (1 mm) |
| Range | 0.16 to 984 feet (0.05 to 300 m) |
| Measuring Units | m, ft, in |
| Recall Last Values | N/A |
| Warranty | Lifetime |
| Smallest Unit Displayed | ±1/32 in (0.1 mm) |
|
Laser
|
|
| Wavelength | 635 nm, < 1 mW |
| Classification | 2 |
| Pointer | 4x |
|
Battery/Power
|
|
| Battery Life | Up to 4000 measurements |
| Power Source | Li-ion Battery |
|
Temperature Range
|
|
| Storage | -13 to 140 °F (-25 to 60 °C) |
| Operation | 14 to 122 °F (-10 to 50 °C) |
| Charging | 14 to 104 °F (-10 to 40 °C) |
|
Tilt/Inclination Sensor
|
|
| Measurement Range | 360 degrees |
| Accuracy to Laser Beam | -0.1° / +0.2° |
| Accuracy to Housing | ±0.1 degree |
| Indirect Measurements (direct horizontal distance) | Yes |
| Angle Measurements | Yes |
|
Automatic Power Off
|
|
| Laser | Up to 90 seconds |
| Instrument | Up to 180 seconds |
|
Functions
|
|
| Continuous Distance Measuring | Yes |
| Min/Max Measuring | Yes |
| Stake-out | Yes |
| Addition/Subtraction | Yes |
| Area/Volume | Yes/Yes |
| Triangle Area | Yes |
| Partial Measurement Room Area (Painter Function) | Yes |
| Pythogoras (Indirect Measurements) | 2 point, 3 point |
| Smart Horizontal Mode™ (Indirect Height) | Yes |
| Height Tracking (without suitable reflective point) | Yes |
| Beep | Yes |
| Timer | Yes |
| Trapezium measurements (slopes & facade areas) | Yes |
| Height Profile Measurements | Yes |
|
Extra Technology
|
|
| Digital Pointfinder (4-fold zoom) | Yes |
| Bluetooth | Yes |
| Free Software Leica Disto™ Transfer with AutoCAD Plug-In | N/A |
| Power Range Technology™ | N/A |
| Personalized Favorites | Yes |
| Bluetooth Smart | N/A |
| Measure with a Picture | N/A |
| Built-in Calculator | Yes |
|
Features
|
|
| Multifunctional Endpiece | N/A |
| Tripod Thread | N/A |
| Display | Illuminated, color |
| Protection Class | IP54 dustproof and water splash resistant |
| Built-in Bubble Vial | N/A |
| Sound Wave Technology | N/A |
| Optical Sight | N/A |
| Temperature Compensation | N/A |
| Ultrasonic Frequency Indicator | N/A |
| Free Downloadable Sketch App | N/A |
| Drop Performance | N/A |
| Signal Strength Indicator | N/A |
| Side Measure Button | N/A |
| Extension Tab Auto Detected | N/A |
| Viewfinder | N/A |
| Free Downloadable Mobile App | N/A |
| Pocket Clip | N/A |
